🔥 Fire Extinguisher Installation Guide for Shops (<200 m²) – Portugal
Learn how to install fire extinguishers in stores smaller than 200 m² in Portugal. Complete guide with types, location, signage and maintenance.
Why install fire extinguishers in stores?
-
Mandatory in Portugal for stores with an area of less than 200 m².
-
Ensures initial response to fires.
-
Protects people and equipment.
-
Complies with SCIE legislation and NP 4413 standards.
Recommended Types of Fire Extinguishers
| Extinguisher | Capacity | Recommended use |
|---|---|---|
| 🔴 ABC | 6 kg | Class A, B and C fires (solid, liquid and gaseous materials) |
| • CO₂ | 2 kg | Electrical hazards (electrical panels, cash registers, electronic equipment) |
Ideal Location
-
ABC fire extinguisher : near the main entrance/exit.
-
CO₂ fire extinguisher : near electrical equipment
Tips:
-
Maximum distance: 15 m
-
Never behind doors or furniture.
-
Visible and unobstructed locations
Height and Fixing
-
Fire extinguisher handle: ~4 feet from the ground
-
Attach to the wall or a stable support.
-
It must allow for quick and safe removal.
Fire Extinguisher Signage
-
Fire extinguisher sign : 2.10 m from the ground
-
Fire extinguisher sign : 1.50 m from the ground
-
ISO 7010 standards
-
Visible, legible, and unobstructed signs
Maintenance and Inspections
-
🔧 Mandatory annual inspection
-
🏷️ Visible maintenance label
-
Refill or replace after use.
Training and Best Practices
-
Employees should know:
-
Location of fire extinguishers
-
Type of fire extinguisher and associated risk
-
-
Training in first response to fire
Final Summary
-
2 portable fire extinguishers : ABC 6 kg + CO₂ 2 kg
-
Height of the fire extinguisher: 4 feet
-
Signage: fire extinguisher 2.10 m | agent 1.50 m
-
Maximum distance: 15 m
-
Mandatory annual maintenance
